| Sr. No. |
Specification |
Technical Parameter |
| 1 |
Dimension of Sliding Table |
3200mm x 360mm |
| 2 |
Gross Cut Capacity |
3200mm x 360mm |
| 3 |
Width of Cut Between Saw Blade and Rip Fence |
1250mm |
| 4 |
Saw Blade Diameter |
300m (250-300) |
| 5 |
Height of Cut |
80mm |
| 6 |
Speed of Main Saw Spindle |
4000/6000rpm |
| 7 |
Spindle Diameter |
30mm |
| 8 |
Tilting Saw Blade |
0-45" |
| 9 |
Main Motor |
5.5k.w. |
| 10 |
Scoring Saw Blade Diameter |
120mm |
| 11 |
Speed of Scoring Saw Blade |
9000r/min |
| 12 |
Scoring Spindle Diameter |
20mm |
| 13 |
Scoring Motor |
0.75kw |
| 14 |
Overall Dimension |
3250 x 3250 x 900 (mm) |
