| Sr. No. |
Specification |
Unit |
Technical Parameter |
| 1 |
Drive Motors |
|
Stepper Motor & Drive |
| 2 |
Controls |
|
Digital Signal Processor Rich Auto A11E |
| 3 |
X-Y Movement |
|
X Axis Motion 30 mm Ball screw |
| 4 |
Z Movement |
|
25mm,Ball Screw Drive, THK |
| 5 |
Computer interface |
|
USB 2.0 |
| 6 |
Command Code |
|
G Code |
| 7 |
Spindle |
|
3.2 KW, Air Cooling, 18000 RPM, |
| 8 |
Oil Lubrication System |
|
Standard |
| 9 |
Working Voltage |
|
AC 380V / IIz,3 Ø |
| 10 |
Software |
|
xxxxxxxxxxx |
| 11 |
Maximum Speed |
mm/min |
35000 |
| 12 |
Resolutions |
mm |
0.025 |
| 13 |
X-Y-Z Axis Working Area |
mm |
1000 x 150 x 50 |
| 14 |
Maximum Cutting Speed |
mm/min |
25000 |
| 15 |
Collet Type & Size |
mm |
ER 25 (12.7, 6, 3.175) |
| 16 |
Machine Size |
mm |
2200 x 1200 X 13 |
| 17 |
Spindle |
mm |
2400 x 1400 x 1500 |
| 18 |
Approx. Weight |
kgs 1 |
1200 |
